| Форма |
ASTM |
| Прут, брус и форма |
276, 484 |
| Плита, лист и полоса |
240, 480 |
| Seamless and welded pipe |
790, 999 |
| Seamless and welded tubing |
789, 1016 |
| Фитинги |
815, 960 |
| Кованые или катаные трубы фланцевые и кованые фитинги |
182, 961 |
| Billet and bar for forging |
314, 484 |
Химический состав
| % |
Fe |
Cr |
Ni |
Mo |
C |
Mn |
Si |
P |
S |
Cu |
N |
| мин |
баланс |
24.0 |
6.0 |
3.0 |
|
|
|
|
|
|
0.24 |
| Макс |
26.0 |
8.0 |
5.0 |
0.030 |
1.20 |
0.80 |
0.035 |
0.020 |
0.50 |
0.32 |
Физические свойства
| Плотность |
7.75 г / cm3 |
| Диапазон плавления |
1396-1450 ℃ |
Особенности: 2507 is a super duplex stainless steel with higher alloy content, thus making it superior to 2205 in corrosion resistance and strength. It has excellent resistance to uniform, pitting, crevice corrosion and chloride stress corrosion cracking. In dilute sulfuric acid contaminated with chloride ions, 2507 has better corrosion resistance than 904L, which is specially designed to resist pure sulfuric acid. Because 2507’s low carbon content greatly lowers the risk of carbide precipitation at the grain boundaries during heat treatment, it is highly resistant to carbide-related intergranular corrosion. 2507 is not suitable for which require long exposure to temperatures above 300℃ because of the increased risk of a reduction in toughness. Its yield strength is about twice that of conventional austenitic stainless steels.
Приложения: Chemical processing industry piping, vessels and heat exchangers; desalination plant seawater piping; oil and gas industry equipment; power plant flue gas desulfurization systems, scrubber systems and absorber towers; and chemical tankers.
|
|
